REF PART
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PART
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
6-2
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
L421 6200002041 S.COI NLV25T-101J-PF T 169/154.5
L422 6200010820 S.COI C2520C-2R7G-A T 172/148.8
L431 6200002041 S.COI NLV25T-101J-PF T 169.9/137.2
L432 6200010790 S.COI C2520C-3R9G-A T 176.7/139.3
L461 6200002041 S.COI NLV25T-101J-PF T 179/155.3
L462 6200010820 S.COI C2520C-2R7G-A T 178.1/161.7
L471 6200010450 S.COI C2520C-R82G-A (0.82U) T 176.5/166.4
L472 6200010450 S.COI C2520C-R82G-A (0.82U) T 177.3/170.1
L491 6200002041 S.COI NLV25T-101J-PF T 169/166.4
L492 6200010820 S.COI C2520C-2R7G-A T 172.5/160.7
L511 6140003210 S.COI LR-358 T 171.8/14.6
L527 6200010740 S.COI C2520C-R27G-A T 172.1/47.4
L529 6200010740 S.COI C2520C-R27G-A T 172.3/42.7
L531 6200011670 S.COI LQW18AN82NG00D T 166.8/13.0
L532 6200011670 S.COI LQW18AN82NG00D T 164.9/13.8
L561 6140004680 S.COI LR-528 4KBL T 153.5/24.5
L651 6200014470 S.COI LQH44PN100MP0L T 9.7/58.5
L652 6190002110 S.COI 7E03LA-2R7N-RB-0231 T 19.1/57.1
R1 7030005090 S.RES ERJ2GEJ 104 X (100K) T 11.3/140.2
R2 7030005050 S.RES ERJ2GEJ 103 X (10K) T 11.3/138.3
R3 7030005050 S.RES ERJ2GEJ 103 X (10K) T 6.5/138.7
R11 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/31.6
R12 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/32.6
R13 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/33.6
R14 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/34.6
R15 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/36.8
R16 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/37.7
R17 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/38.7
R18 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/39.7
R19 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/40.7
R20 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/41.8
R21 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/42.7
R22 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.2/43.7
R23 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.0/32.3
R24 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.0/33.2
R25 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.0/34.2
R26 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.0/35.2
R27 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/37.3
R28 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/38.2
R29 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/39.2
R30 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/40.2
R31 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/41.2
R32 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/42.2
R33 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/43.2
R34 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.9/44.2
R41 7410001240 S.ARR EXB28V220JX T 78.7/26.9
R42 7410001240 S.ARR EXB28V220JX T 81.3/26.9
R43 7410001240 S.ARR EXB28V220JX T 83.9/26.9
R44 7410001240 S.ARR EXB28V220JX T 86.5/26.9
R45 7030007250 S.RES ERJ2GEJ 220 X (22) T 77.5/18.1
R46 7030007250 S.RES ERJ2GEJ 220 X (22) T 78.5/18.1
R47 7030007250 S.RES ERJ2GEJ 220 X (22) T 89.8/26.9
R48 7030007250 S.RES ERJ2GEJ 220 X (22) T 78.0/11.2
R49 7030007250 S.RES ERJ2GEJ 220 X (22) T 90.9/26.9
R50 7410001230 S.ARR EXB28V101JX T 81.4/18.3
R51 7030005090 S.RES ERJ2GEJ 104 X (100K) T 13.0/149.0
R52 7030005070 S.RES ERJ2GEJ 683 X (68K) T 13.0/150.0
R53 7030005220 S.RES ERJ2GEJ 223 X (22K) T 11.1/150.0
R54 7030005220 S.RES ERJ2GEJ 223 X (22K) T 7.6/146.7
R55 7030005120 S.RES ERJ2GEJ 102 X (1K) T 14.6/144.9
R56 7030005100 S.RES ERJ2GEJ 154 X (150K) T 12.7/144.9
R57 7030005090 S.RES ERJ2GEJ 104 X (100K) T 14.7/143.7
R71 7030005240 S.RES ERJ2GEJ 473 X (47K) T 56.5/26.2
R72 7030005120 S.RES ERJ2GEJ 102 X (1K) T 59.3/27.4
R73 7410001340 S.ARR EXB28V473JX T 54.5/21.8
R74 7410001340 S.ARR EXB28V473JX T 55.2/7.9
R75 7030004980 S.RES ERJ2GEJ 101 X (100) T 56.3/9.9
R76 7030009530 S.RES ERJ2GEJ 270 X (27) T 54.2/10.6
R77 7030009530 S.RES ERJ2GEJ 270 X (27) T 56.8/19.4
R78 7030009530 S.RES ERJ2GEJ 270 X (27) T 57.8/19.4
R79 7030004980 S.RES ERJ2GEJ 101 X (100) T 52.8/19.4
R80 7030009530 S.RES ERJ2GEJ 270 X (27) T 53.8/19.4
R81 7030009530 S.RES ERJ2GEJ 270 X (27) T 57.3/9.9
R82 7030009530 S.RES ERJ2GEJ 270 X (27) T 54.8/19.4
R84 7030004980 S.RES ERJ2GEJ 101 X (100) T 48.8/18.1
R85 7030005240 S.RES ERJ2GEJ 473 X (47K) T 62.6/26.3
R86 7030005120 S.RES ERJ2GEJ 102 X (1K) T 64.5/26.3
R87 7030010040 S.RES ERJ2GEJ-JPW T 49.8/18.1
R88 7030010040 S.RES ERJ2GEJ-JPW T 50.8/18.1
R89 7030010040 S.RES ERJ2GEJ-JPW T 50.3/11.3
R90 7030005050 S.RES ERJ2GEJ 103 X (10K) T 84.9/16.3
R101 7030010040 S.RES ERJ2GEJ-JPW T 21.4/132.5
R102 7030005050 S.RES ERJ2GEJ 103 X (10K) T 19.6/132.5
R103 7030012480 S.RES ERJ2RKF 1003X (100K) T 18.8/118.6
R104 7030011670 S.RES ERJ2RKF 3902 (39K) T 17.1/117.6
R105 7030010040 S.RES ERJ2GEJ-JPW T 10.9/132.6
R106 7030012260 S.RES ERJ2RKD 4703X (470K) T 9.6/118.8
R107 7030005050 S.RES ERJ2GEJ 103 X (10K) T 7.7/117.8
R108 7030012480 S.RES ERJ2RKF 1003X (100K) T 7.7/118.8
R121 7030010040 S.RES ERJ2GEJ-JPW T 20.7/107.4
R122 7030012270 S.RES ERJ2RKD 1203X (120K) T 20.0/92.6
R123 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 19.6/94.1
R124 7030005331 S.RES ERA3YED 562V (5.6K) T 17.5/94.0
R131 7030010040 S.RES ERJ2GEJ-JPW T 10.3/107.7
R132 7030012260 S.RES ERJ2RKD 4703X (470K) T 9.9/92.8
R133 7030011670 S.RES ERJ2RKF 3902 (39K) T 9.5/94.0
R134 7030012480 S.RES ERJ2RKF 1003X (100K) T 7.9/94.0
R141 7030010040 S.RES ERJ2GEJ-JPW T 8.7/73.8
R142 7030005641 S.RES ERA3YKD 753V (75K) T 22.3/71.2
R143 7030010040 S.RES ERJ2GEJ-JPW T 23.3/69.9
R144 7030014250 S.RES ERJ2RKF5603X (560K) T 23.3/68.2
R151 7030010040 S.RES ERJ2GEJ-JPW T 12.6/62.8
R153 7030005050 S.RES ERJ2GEJ 103 X (10K) T 12.6/65.0
R155 7030005681 S.RES ERA3YKD 473V (47K) T 21.6/65.5
R156 7030012480 S.RES ERJ2RKF 1003X (100K) T 21.6/62.7
R161 7030005000 S.RES ERJ2GEJ 471 X (470) T 30.4/62.4
R162 7030005050 S.RES ERJ2GEJ 103 X (10K) T 31.9/62.9
R163 7030005050 S.RES ERJ2GEJ 103 X (10K) T 33.8/66.4
R181 7030014120 S.RES LTR50UZPJ6R8 T 144.6/170.5
R182 7030014120 S.RES LTR50UZPJ6R8 T 149.4/166
R191 7030005090 S.RES ERJ2GEJ 104 X (100K) T 33.1/20.1
R192 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 28.2/23.6
R221 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 75.7/129.8
R222 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 72.3/129.8
R224 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 79.4/137.9
R226 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 77.2/137.8
R227 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 79.3/141.5
R229 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 77.1/141.0
R230 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 75.1/144.6
R231 7030013630 S.RES ERJ2RHD 1002X (10.0K) T 71.6/144.5
R233 7030004980 S.RES ERJ2GEJ 101 X (100) T 75.0/134.5
R234 7030005090 S.RES ERJ2GEJ 104 X (100K) T 73.7/135.0
R235 7030010040 S.RES ERJ2GEJ-JPW T 48.6/135.9
R236 7030010040 S.RES ERJ2GEJ-JPW T 50.6/135.8
R239 7030005120 S.RES ERJ2GEJ 102 X (1K) T 69.3/144.1
R240 7030005120 S.RES ERJ2GEJ 102 X (1K) T 69.7/131.5
R242 7030005600 S.RES ERJ2GEJ 273 X (27K) T 140/123.6
R243 7030005050 S.RES ERJ2GEJ 103 X (10K) T 135/123.2
R244 7030005240 S.RES ERJ2GEJ 473 X (47K) T 133/132.3
R245 7030005120 S.RES ERJ2GEJ 102 X (1K) T 140.4/125.4
R246 7030008290 S.RES ERJ2GEJ 183 X (18K) T 141.3/132.3
R247 7030007340 S.RES ERJ2GEJ 153 X (15K) T 139.0/131.9
R248 7030005050 S.RES ERJ2GEJ 103 X (10K) T 138.4/131.0
R249 7030005530 S.RES ERJ2GEJ 100 X (10) T 132.9/133
R250 7030005530 S.RES ERJ2GEJ 100 X (10) T 143.3/150
R251 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 142.7/159.9
R252 7030007160 S.RES ERJ12YJ3R3U (3.3) T 151.9/147.5
R253 7030007160 S.RES ERJ12YJ3R3U (3.3) T 148.1/147.5
R254 7030005110 S.RES ERJ2GEJ 224 X (220K) T 133.1/167.0
R255 7030005110 S.RES ERJ2GEJ 224 X (220K) T 131.4/167.0
R256 7030005050 S.RES ERJ2GEJ 103 X (10K) T 125.6/167.6
R257 7030005240 S.RES ERJ2GEJ 473 X (47K) T 126.8/167.1
R258 7030005120 S.RES ERJ2GEJ 102 X (1K) T 130.7/173.9
R259 7030007280 S.RES ERJ2GEJ 331 X (330) T 130.7/174.9
R261 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 107.8/171.7
R266 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 109.1/171.2
R271 7030008400 S.RES ERJ2GEJ 182 X (1.8K) T 167.0/64.6
R272 7030005710 S.RES ERJ2GEJ 121 X (120) T 167.4/63.3
R275 7030011450 S.RES ERJ2RKF 49R9X (49.9) T 171.3/60.9
R281 7030005580 S.RES ERJ2GEJ 560 X (56) T 174.7/69.1
R282 7030005530 S.RES ERJ2GEJ 100 X (10) T 173.5/69.4
R284 7030008400 S.RES ERJ2GEJ 182 X (1.8K) T 172.3/71.5
R285 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 174.7/71.5
R286 7030004990 S.RES ERJ2GEJ 221 X (220) T 177.7/72.2
R287 7030010040 S.RES ERJ2GEJ-JPW T 173.1/77.7
R291 7030010040 S.RES ERJ2GEJ-JPW T 178.0/81.5
R293 7030004980 S.RES ERJ2GEJ 101 X (100) T 165.1/77.9
R294 7030004970 S.RES ERJ2GEJ 470 X (47) T 164.0/73.2
R295 7030010040 S.RES ERJ2GEJ-JPW T 176.5/81.9
R296 7030010040 S.RES ERJ2GEJ-JPW T 175.0/67.2
R297 7030004970 S.RES ERJ2GEJ 470 X (47) T 177.7/73.2
R298 7030010040 S.RES ERJ2GEJ-JPW T 180.2/85.9
R299 7030010040 S.RES ERJ2GEJ-JPW T 173.8/86.0
R303 7030005240 S.RES ERJ2GEJ 473 X (47K) T 44.9/150.4
R304 7030005050 S.RES ERJ2GEJ 103 X (10K) T 103.6/146
R305 7030005050 S.RES ERJ2GEJ 103 X (10K) T 103/143.9
R306 7030005050 S.RES ERJ2GEJ 103 X (10K) T 88.5/145.4
R307 7030005050 S.RES ERJ2GEJ 103 X (10K) T 88.5/143.7
R308 7030005090 S.RES ERJ2GEJ 104 X (100K) T 100.2/144
R309 7030005090 S.RES ERJ2GEJ 104 X (100K) T 89.8/144.0
R310 7030005090 S.RES ERJ2GEJ 104 X (100K) T 100.1/145.5
R311 7030005090 S.RES ERJ2GEJ 104 X (100K) T 89.8/145.0
R312 7030004980 S.RES ERJ2GEJ 101 X (100) T 98.8/147.9
R313 7030005240 S.RES ERJ2GEJ 473 X (47K) T 100.8/149
R314 7030005120 S.RES ERJ2GEJ 102 X (1K) T 99.8/153.9
R315 7030005160 S.RES ERJ2GEJ 105 X (1M) T 99.8/155.5
R317 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 90.4/162.8
R319 7030007340 S.RES ERJ2GEJ 153 X (15K) T 61.3/167.2
R320 7030009530 S.RES ERJ2GEJ 270 X (27) T 62.5/167.6
R321 7030007340 S.RES ERJ2GEJ 153 X (15K) T 61.3/165.4
R322 7030009530 S.RES ERJ2GEJ 270 X (27) T 62.5/164.9
R324 7030004970 S.RES ERJ2GEJ 470 X (47) T 65.3/174.7
R325 7030005090 S.RES ERJ2GEJ 104 X (100K) T 71.9/168.0
R326 7030009530 S.RES ERJ2GEJ 270 X (27) T 62.5/158.6
R327 7030007340 S.RES ERJ2GEJ 153 X (15K) T 61.3/159.1
R328 7030005691 S.RES ERA3YED 123V (12K) T 64.1/169.4
R329 7030007340 S.RES ERJ2GEJ 153 X (15K) T 64.4/157.9
R330 7030009530 S.RES ERJ2GEJ 270 X (27) T 64.4/159.6
R331 7030005090 S.RES ERJ2GEJ 104 X (100K) T 75.4/167.6
R332 7030009530 S.RES ERJ2GEJ 270 X (27) T 62.5/164.0
R333 7030007340 S.RES ERJ2GEJ 153 X (15K) T 61.3/163.6
R335 7030009530 S.RES ERJ2GEJ 270 X (27) T 62.5/161.3
R336 7030007340 S.RES ERJ2GEJ 153 X (15K) T 61.3/161.8
R337 7030005090 S.RES ERJ2GEJ 104 X (100K) T 75.4/165.8
R339 7030009530 S.RES ERJ2GEJ 270 X (27) T 69.2/174.8
R340 7030009530 S.RES ERJ2GEJ 270 X (27) T 70.1/174.8
R341 7030005090 S.RES ERJ2GEJ 104 X (100K) T 41.1/149.4
R342 7030005090 S.RES ERJ2GEJ 104 X (100K) T 42.0/149.4
R345 7030005050 S.RES ERJ2GEJ 103 X (10K) T 57.9/150.2
R346 7030005050 S.RES ERJ2GEJ 103 X (10K) T 55.9/150.2
R347 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 60.8/155.4
R349 7030007250 S.RES ERJ2GEJ 220 X (22) T 41.1/147.3
R350 7030007250 S.RES ERJ2GEJ 220 X (22) T 42.0/147.3
R351 7030007250 S.RES ERJ2GEJ 220 X (22) T 47.4/150.8
R352 7030005090 S.RES ERJ2GEJ 104 X (100K) T 50.5/154.1
R353 7030005090 S.RES ERJ2GEJ 104 X (100K) T 49.2/147.3
To Next Page
Loading...
