This service manual describes the latest service information
for the IC-R9500 COMMUNICATIONS RECEIVER at the
time of publication.
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than specified. This will ruin
the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the receiver’s
front end.
To upgrade quality any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
MODEL VERSION FREQUENCY COVERAGE (MHz)
IC-R9500
[USA]
0.005–821.999999,
851.000000–866.999999,
896.000000–3335.000000
[FRA]
0.0050000–29.999999,
50.200000–51.200000,
87.500000–108.000000,
144.000000–146.000000,
430.000000–440.000000,
1240.000000–1300.000000
[USA-01]
0.005–3335.000000
[EUR]
[UK]
[CAN]
[EXP]
[AUS]
[CHN]
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and UNIT name
4. Quantity required
<SAMPLE ORDER>
1110006750 S.IC TK14570L IC-R9500 RF-A UNIT 5 pieces
8820001210 Screw 2844 screw IC-R9500 CHASSIS 10 pieces
Addresses are provided on the inside back cover for your
convenience.
Icom Icom Inc. and logo are registered trademarks of Icom Incorporated (Japan) in the United States the United
Kingdom Germany France Spain Russia and/or other countries.
ORDERING PARTS
1. Make sure a problem is internal before disassembling
the receiver.
2. DO NOT open the receiver until the receiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An
insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
receiver is defective.
6. READ the instructions of test equipment throughly
before connecting equipment to the receiver.
REPAIR NOTES
INTRODUCTION CAUTION
