S.=Surface mount
C64 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C67 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C68 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C70 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C71 4030012610 S.CERAMIC C2012 JB 1C 474K-T-A
C72 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C73 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C74 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C75 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
C76 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
C77 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C78 4510005370
S.ELECTROLYTIC
ECEV1AA221P
C80 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C81 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C83 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C84 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C88 4510004630
S
.ELECTROLYTIC
ECEV1CA100SR
C89 4510004630
S.ELECTROLYTIC
ECEV1CA100SR
C90 4510004630
S.ELECTROLYTIC
ECEV1CA100SR
C91 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C92 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C93 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C94 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C95 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C96 4510004640
S.ELECTROLYTIC
ECEV1CA470SP
C97 4550006480 S.TANTALUM TEMSVA 1C 475M-8L
C98 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C99 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C100 4550000550 S.TANTALUM TESVA 1V 224M1-8L
C101 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C102 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C103 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C104 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C105 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C107 4510004630
S.ELECTROLYTIC
ECEV1CA100SR
C108 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C109 4510004630
S.ELECTROLYTIC
ECEV1CA100SR
C110 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C113 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C114 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C115 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C116 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C117 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C119 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C120 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C121 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C122 4550006080 S.TANTALUM TEMSVB2 1C 106M-8L
C123 4030009570 S.CERAMIC C1608 CH 1H 0R3B-T-A
C124 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C125 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C126 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C128 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
C129 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C130 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C131 4030006970 S.CERAMIC C1608 CH 1H 060D-T-A
C132 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C133 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C134 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C135 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C136 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C137 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C138 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C140 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C141 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C145 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C146 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C149 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C150 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C151 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C153 4030006920 S.CERAMIC C1608 CH 1H 010C-T-A
C154 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C155 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C156 4030006940 S.CERAMIC C1608 CH 1H 030C-T-A
C206 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
CP1 6910009670 S.CHECK P HK3-S-T
CP2 6910009670 S.CHECK P HK3-S-T
J1 6510003570 CONNECTOR S09B-EH-S
J2 6510003510 CONNECTOR S03B-EH-S
J3 6510013350 CONNECTOR C05-LR-03
W1 7030003860 S.JUMPER ERJ3GE JPW V
W7 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910050502 PCB B 5198B
IC1 1180000970 S.IC AN78L05M-(E1)
IC2 1110002870 S.IC AN8003M-(E1)
IC3 1140005990 S.IC MB15A02PFV1-G-BND-ER
IC4 1110002750 S.IC TA75S01F (TE85R)
IC5 1110000960 S.IC NJM4558M-T1
IC6 1110002750 S.IC TA75S01F (TE85R)
Q1 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q2 1530003670 S.TRANSISTOR 2SC5186-T1
Q3 1530002940 S.TRANSISTOR 2SC4228-T2 R44
Q4 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q5 1530000370 S.TRANSISTOR 2SC3356-T2B
Q6 1590002600 S.FET MRF9745 T1
Q8 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q9 1590000680 S.TRANSISTOR DTC114EUA T106
Q10 1510000820 S.TRANSISTOR 2SA1587-BL (TE85R)
Q11 1530003000 S.TRANSISTOR 2SC4117-BL (TE85R)
Q12 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q13 1590001390 S.FET 2SJ144-Y (TE85R)
Q14 1560000540 S.FET 2SK880-Y (TE85R)
D1 1750000550 S.DIODE 1SS355 TE-17
D2 1790001310 S.VARICAP 1SV270(TPH3)
D3 1790001310 S.VARICAP 1SV270(TPH3)
D5 1750000550 S.DIODE 1SS355 TE-17
D6 1790000950 S.ZENER MA8056-M(TX)
X1 6050010280 S.XTAL CR-608 (12.800 MHz)
L1 6200003640 S.COIL MLF1608K 100K-T
L2 6200003640 S.COIL MLF1608K 100K-T
L3 6200004130 S.COIL MC152-E558ANA-100053
L4 6200005740 S.COIL ELJRE 47NG-F
L5 6200005720 S.COIL ELJRE 33NG-F
L6 6200005690 S.COIL ELJRE 18NG-F
L7 6200005680 S.COIL ELJRE 15NG-F
L8 6200003450 S.COIL NL 322522T-082J
L9 6200004170 S.COIL NL 322522T-012J
L10 6200001830 S.COIL NL 322522T-100J
R1 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R2 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R3 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R4 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R5 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R6 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R7 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R9 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R10 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R11 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R12 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R13 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R14 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R17 7030000250 S.RESISTOR MCR10EZHJ 82 Ω (820)
R18 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R19 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R20 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
4 - 5
REF ORDER
DESCRIPTION
NO. NO.
[RX UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RX UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[TX UNIT]
