Icom IC-UR8050 - Page 19

S.=Surface mount
R21 7030001010 S.RESISTOR MCR50JZHJ 10 Ω (100)
R22 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R23 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R24 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R25 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R26 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R27 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R28 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R29 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R30 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R31 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R32 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R33 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R34 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R35 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R36 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R38 7310002760 S.TRIMMER RV-152 (RH03A3AJ4X0HA) 223
R39 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R40 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R43 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R44 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R45 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R46 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R47 7510000200 S.THERMISTOR TN20-3U473LT
R48 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R49 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R50 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R51 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R52 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R53 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R56 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R57 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R58 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R59 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R60 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R68 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R69 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R70 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R71 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R72 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R73 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R74 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R75 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R76 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R77 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R78 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) [wide]
7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) [narrow]
R79 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R80 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R81 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R82 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R83 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R84 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R85 7030001010 S.RESISTOR MCR50JZHJ 10 Ω (100)
R86 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R87 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R89 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R90 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
C1 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C3 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C4 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C5 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C6 4550000510 S.TANTALUM TESVA 1V 473M1-8L
C7 4030008880 S.CERAMIC C1608 JB 1C 223K-T-A
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C9 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C10 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C11 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C13 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C15 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C17 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C18 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C19 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
C20 4030009510 S.CERAMIC C1608 CH 1H 010B-T-A
C21 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C22 4030009570 S.CERAMIC C1608 CH 1H 0R3B-T-A
C23 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C24 4550006770 S.TANTALUM TEMSVD2 1C 476M-12R
C25 4030006940 S.CERAMIC C1608 CH 1H 030C-T-A
C26 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C29 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C30 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C32 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C37 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C39 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C41 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C42 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C44 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C45 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C46 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C47 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C48 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C49 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C51 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C52 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C53 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C54 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C55 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C56 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C57 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C58 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C59 4510005300 S.ELECTROLYTIC ECEV1AA330SR
C61 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C62 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C63 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C64 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C65 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C66 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C67 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C68 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C69 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C70 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C74 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
C75 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C76 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C77 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C78 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C79 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C80 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C81 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C83 4030009590 S.CERAMIC C2012 JF 1C 225Z-T-A
C84 4510004630 S.ELECTROLYTIC ECEV1CA100SR
CP1 6910009670 S.CHECK P HK3-S-T
J1 6510003560 CONNECTOR S08B-EH-S
J2 6510003510 CONNECTOR S03B-EH-S
J3 6510003510 CONNECTOR S03B-EH-S
J4 6510013350 CONNECTOR C05-LR-03
J5 6910004740 CONNECTOR IMSA-9202B-1-03T
P1 6910003120 CONNECTOR IMSA-9206H-T
EP1 0910050512 PCB B 5199B
4 - 6
REF ORDER
DESCRIPTION
NO. NO.
[TX UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[TX UNIT]
