S.=Surface mount
R21 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R22 7510000850 S.THERMISTOR NTCCF2012 3BH 102KC-T
R23 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
C1 4030011080 S.CERAMIC GRM42-6 CH 060D 500PT
C2 4030011070 S.CERAMIC GRM42-6 CH 050C 500PT
C3 4030011020 S.CERAMIC GRM42-6 CK 010C 500PT
C4 4030011080 S.CERAMIC GRM42-6 CH 060D 500PT
C5 4030011110 S.CERAMIC GRM42-6 CH 090D 500PT
C6 4030011050 S.CERAMIC GRM42-6 CJ 030C 500PT
C7 4030011020 S.CERAMIC GRM42-6 CK 010C 500PT
C8 4030011080 S.CERAMIC GRM42-6 CH 060D 500PT
C9 4030011060 S.CERAMIC GRM42-6 CH 040C 500PT
C10 4030011020 S.CERAMIC GRM42-6 CK 010C 500PT
C11 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C12 4510006650
S.ELECTROLYTIC
ECEV 1EA 100SR
C13 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C14 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C15 4510006650
S.ELECTROLYTIC
ECEV 1EA 100SR
C16 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C17 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C18 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C19 4510006650
S.ELECTROLYTIC
ECEV 1EA 100SR
C21 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C24 4510006650
S.ELECTROLYTIC
ECEV 1EA 100SR
C25 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C27 4510006670
S.ELECTROLYTIC
ECEV 1CA 471P
C28 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C32 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C35 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
J1 6510003390 CONNECTOR B03B-EH-S
W1 8900004930 CABLE OPC-481
W4 8900008630 CABLE OPC-845
W6 8900004940 CABLE OPC-482
WS1 8600036340 M.OTHER FX2169 P01*P03PA
EP1 0910050522 PCB B 5200B
4 - 7
REF ORDER
DESCRIPTION
NO. NO.
[PA UNIT]
IC1 1180001320 IC NJM7809FA
D1 1790000700 DIODE DSA3A1
R1 7010004680 RESISTOR
R2 7010004680 RESISTOR
C1 4550002430 TANTALUM DN 1V R33M
C2 4550000320 TANTALUM DN 1V 0R1M
C3 4510004590 ELECTROLYTIC 16 MV 470 HC
C4 4010006880 CERAMIC HE50SJ YB 102K 50V
J1 6510003390 CONNECTOR B03B-EH-S
J2 6510003420 CONNECTOR B06B-EH-S
J3 6510003390 CONNECTOR B03B-EH-S
J4 6510003390 CONNECTOR B03B-EH-S
F1 5220000020 HOLDER S-N5051
F2 5220000020 HOLDER S-N5051
F3 5210000080 FUSE FGB 20A
WS1 8600032860 M.OTHER FX1449 P01RE
WS2 8600036350 FX2169 P02*P07RE
WS3 8600036360 FX2169 P03*P08RE
WS4 8600036370 FX2169 P04*P09RE
WS5 8600033971 FX1624 P05RE-1
WS6 8600036380 FX2169 P06RE
EP1 0910051081 PCB B 5252A
IC1 1150001960 IC M68703LA
IC3 1110002750 S.IC TA75S01F (TE85R)
Q1 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q2 1520000220 TRANSISTOR 2SB1019-Y
D1 1790000980 S.DIODE MA742(TX)
D2 1790000980 S.DIODE MA742(TX)
L1 6110001660 COIL LA-252
L2 6110001660 COIL LA-252
L3 6110001660 COIL LA-252
L4 6110001660 COIL LA-252
L5 6200006190 S.COIL BLM21P300S
L6 6110001990 COIL LA-223
L7 6110002590 COIL LA-239
R1 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R2 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R7 7030001180 S.RESISTOR MCR50JZHJ 270 Ω (271)
R8 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R9 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R10 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R11 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R12 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R13 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R14 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R15 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R16 7310002720 S.TRIMMER RV-148 (RH03A3AS3X0DA) 472
R17 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R20 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[REG UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[PA UNIT]
