NXDN™ IC-F5400D/IC-F6400D SERIES PRODUCT GUIDE
18
• Transparent data mode
The IC-F5400D/IC-F6400D series transceivers have the Transparent data mode. The Transparent data
mode enables data transmission at 3600 bps. This function enables you to transmit simple measuring data,
such as air temperature, or still images for remote monitoring.
Figure 4-2. Transparent data mode application example
• OAA (Over-the Air Alias) function
Even if the IC-F5400D/IC-F6400D series transceivers receive a signal that is not programmed into the Call
List, this function can automatically display and program the caller’s name with an ID. When you add new
transceivers in your system, the transceiver can display the name corresponding to an Individual
ID/Talkgroup ID on the display without reentering, by using this function. If the caller’s name set in the
transceiver is changed, the receiving transceiver automatically changes the ID name.
Figure 4-3. OAA example
• 12.5 kHz Digital mode operation
You can select the channel spacing between 6.25 kHz and 12.5 kHz in the digital mode using the
programming software.
• Field programming by Over-The-Air programming (OTAP) can be done (a license is required.)
Even if you have to change the transceiver settings, you can remotely do it without taking it to your dealer, by
using the OTAP function. Installing the software* for the OTAP function onto the PC is required.
*Available in the near future.
Sending a picture
Office PC
(Viewing the received picture)
Conv ID: 3
Name: TR3
Conv ID: 4
Name: TR4
The ID name “TR3” is automatically programmed as ID 3’s name.
OAA
