NXDN™ IC-F5400D/IC-F6400D SERIES PRODUCT GUIDE
19
• Expanding functions by activation licenses
The IC-F5400D/IC-F6400D series transceivers can expand their functions using an activation license. You
can upgrade the transceiver using the programming software. The license is linked to the transceiver's serial
number. Therefore, a unique license is required for each transceiver. The following licenses are sold, or will
be sold in the near future.
Table 4-4. License list
License name Expanding function
ISL-UGMTR For NXDN™ Type-D trunking operation.
ISL-CHEX To increase channel number from 1,024 to 4,000.
ISL-AK25K For 25 kHz (Wide) operation (only [USA]).
ISL-AKAES For AES encryption operation.
ISL-AKSTM For access to the dealer set mode.
• Programming using a microSD card
You can save the transceiver’s setting on a microSD card, or load the saved setting to the transceiver.
Therefore, you can save or change the setting in the field without using the programming software. So, when
multiple operators share one transceiver, you can easily change the transceiver’s setting for each operator
with this function. A microSD card is required.
• GPS position indication
The IC-F5400D/IC-F6400D series transceivers have a built-in GPS receiver, and current position information
can be displayed on the transceiver’s LCD display. You can know your own position by displaying the
information. You can transmit your position information. The transmitted position is used to display the
transceiver’s position on a map by using a third party AVL system.
In addition, other transceiver’s relative position can be displayed on the display. For example, your
transceiver receives position information from the transceiver whose Individual ID name is ID 2, information
is displayed as shown in figure 4-6.
Figure 4-4. Position information display example
Figure 4-5. ID 2’s position information display example
Latitude
Longitude
Altitude
ID 2’s latitude
ID 2’s longitude
The distance from your
own station to ID 2.
Direction from own
station to ID 2.
