BIA-DPC1 rev 4 Page 21
3.2 Function switch setting - BOOSTING
Installers can set the function switch to meet different applications. Before setting the function switch, the
control panel should be disconnected from the power supply.
After completing the setting, apply power to the control panel and observe the application sign displayed on
the LCD conforming to the BOOSTING symbol.
BOOSTING SETTING BOOSTING SYMBOL
SWITCHES UP
