16
17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included hex key in a secure
place; the hex key is used to adjust the walking belt (see page 27). Note: Extra hardware may be included.
16
16. Carefully slide the Upright Crossbar (108)
between the Left and Right Uprights (89, 90).
Attach the Upright Crossbar with the four 5/16"
x 3/4" Screws (18) and four 5/16" Star Washers
(11); start all four Screws, and then tighten
them.
Firmly tighten the four 1/4" x 1/2" Screws (2).
11
2
18
11
90
89
108
18
2
