ICON PLATFORM NANO User Manual

100
D#1 Select 4
Channel Select
B1 Encoder 4
Press Encoder
E1 Select 5
Channel Select
C2 Encoder 5
Press Encoder
F1 Select 6
Channel Select
C#2 Encoder 6
Press Encoder
F#1 Select 7
Channel Select
D2 Encoder 7
Press Encoder
G1 Select 8
Channel Select
D#2 Encoder 8
Press Encoder
C-1 Rec 1
Channel Rec
E2 Track
Assignment
C#-1 Rec 2
Channel Rec
F2 Send
Assignment
D-1 Rec 3
Channel Rec
F#2 Pan
Assignment
D#-1 Rec 4
Channel Rec
G2 Plugin
Assignment
E-1 Rec 5
Channel Rec
G#2 EQ
Assignment
F-1 Rec 6
Channel Rec
A2 Instrument
Assignment
F#-1 Rec 7
Channel Rec
A#2 Bank Up
Bank 8 Channels
G-1 Rec 8
Channel Rec
B2 Bank Down
Bank 8 Channels
G#-1 Solo 1
Channel Solo
C3 Channel Up
Bank One Channel
A-1 Solo 2
Channel Solo
C#3 Channel Down
Bank One Channel
A#-1 Solo 3
Channel Solo
D3 Flip
Fader Flip Mode
B-1 Solo 4
Channel Solo
D#3 Global View
C0 Solo 5
Channel Solo
A#4 Shift
C#0 Solo 6
Channel Solo
B4 Option
D0 Solo 7
Channel Solo
C5 Control
B+ Only
D#0 Solo 8
Channel Solo
C#5 Cmd
DAW Mode
E0 Mute 1
Channel Mute
C6 Marker
F0 Mute 2
Channel Mute
C#6 Nudge
F#0 Mute 3
Channel Mute
D6 Cycle
G0 Mute 4
Channel Mute
D#6 Drop
G#0 Mute 5
Channel Mute
E6 Replace
A0 Mute 6
Channel Mute
F6 Click
A#0 Mute 7
Channel Mute
F#6 Solo
Region Solo Mode
B0 Mute 8
Channel Mute
D7 Scrub
D4 Global Tracks
! Not mapped
F#4 Global Aux
! Not mapped
D#4 Global Inputs
! Not mapped
G4 Global Bus
! Not mapped
E4 Global Audio
! Not mapped
G#4 Global Output
! Not mapped
F4 Global Instrument
! Not mapped
A4 Global User
! Not mapped
D5 Read
Automation
D#5 Write
Automation
E5 Trim
Automation
F5 Touch
Automation
F#5 Latch
Automation
G5 Group
E3 Name/Value
Display
F3 SMPTE/Beats
Display
F#3 F1
Function
G3 F2
Function
G#3 F3
Function
A3 F4
Function
A#3 F5
Function
B3 F6
Function
C4 F7
Function
C#4 F8
Function
A6 Stop
A#6 Play
B6 Record
Main record
C7 Cursor Up
^
C#7 Cursor Left
<
D#7 Zoom
E7 Cursor Right
>
F7 Cursor Down
v
G6 Rewind
<<
G#6 Fast Forward
>>
G#5 Save
QCon Pro X, B+ only
A5 Undo
QCon Pro X, B+ only
A#5 Cancel
QCon Pro X, B+ only
B5 Enter
QCon Pro X, B+ only
MIDI FunctionI nfoM IDMIDI FunctionI nfo
Ch
1 Logic Pro X Ch1 Logic Pro X
C1 Select 1
Channel Select
G#1 Encoder 1
Press Encoder
C#1 Select 2
Channel Select
A1 Encoder 2
Press Encoder
D1 Select 3
Channel Select
A#1 Encoder 3
Press Encoder
D#1 Select 4
Channel Select
B1 Encoder 4
Press Encoder
E1 Select 5
Channel Select
C2 Encoder 5
Press Encoder
F1 Select 6
Channel Select
C#2 Encoder 6
Press Encoder
F#1 Select 7
Channel Select
D2 Encoder 7
Press Encoder
G1 Select 8
Channel Select
D#2 Encoder 8
Press Encoder
C-1 Rec 1
Channel Rec
E2 Track
Assignment
C#-1 Rec 2
Channel Rec
F2 Send
Assignment
D-1 Rec 3
Channel Rec
F#2 Pan
Assignment
D#-1 Rec 4
Channel Rec
G2 Plugin
Assignment
E-1 Rec 5
Channel Rec
G#2 EQ
Assignment
F-1 Rec 6
Channel Rec
A2 Instrument
Assignment
F#-1 Rec 7
Channel Rec
A#2 Bank Up
Bank 8 Channels
G-1 Rec 8
Channel Rec
B2 Bank Down
Bank 8 Channels
G#-1 Solo 1
Channel Solo
C3 Channel Up
Bank One Channel
A-1 Solo 2
Channel Solo
C#3 Channel Down
Bank One Channel
A#-1 Solo 3
Channel Solo
D3 Flip
Fader Flip Mode
B-1 Solo 4
Channel Solo
D#3 Global View
C0 Solo 5
Channel Solo
A#4 Shift
C#0 Solo 6
Channel Solo
B4 Option
D0 Solo 7
Channel Solo
C5 Control
B+ Only
D#0 Solo 8
Channel Solo
C#5 Cmd
DAW Mode
E0 Mute 1
Channel Mute
C6 Marker
F0 Mute 2
Channel Mute
C#6 Nudge
F#0 Mute 3
Channel Mute
D6 Cycle
G0 Mute 4
Channel Mute
D#6 Drop
G#0 Mute 5
Channel Mute
E6 Replace
A0 Mute 6
Channel Mute
F6 Click
A#0 Mute 7
Channel Mute
F#6 Solo
Region Solo Mode
B0 Mute 8
Channel Mute
D7 Scrub
D5 Read
Automation
D#5 Write
Automation
E5 Trim
Automation
F5 Touch
Automation
F#5 Latch
Automation
G5 Group
E3 Name/Value
Display
F3 SMPTE/Beats
Display
F#3 F1
Function
G3 F2
Function
G#3 F3
Function
A3 F4
Function
A#3 F5
Function
B3 F6
Function
A6 Stop
A#6 Play
B6 Record
Main record
C7 Cursor Up
^
C#7 Cursor Left
<
D#7 Zoom
E7 Cursor Right
>
F7 Cursor Down
v
G6 Rewind
<<
G#6 Fast Forward
>>
G#5 Save
QCon Pro X, B+ only
A5 Undo
QCon Pro X, B+ only
A#5 Cancel
QCon Pro X, B+ only
B5 Enter
QCon Pro X, B+ only

ICON PLATFORM NANO Specifications

General

Connectivity	USB
Compatibility	Windows, macOS
Power Supply	USB Bus Powered
Transport Controls	Yes
USB	USB 2.0
Footswitch	1 footswitch connector
Inputs	1 x Footswitch
Faders	1 x Touch-sensitive motorized fader with 10-bit resolution
Display	12-segment LED display
