ICON PLATFORM NANO User Manual

99
A6 Stop
A#6 Play
B6 Record
Main record
C7 Cursor Up
^
D7 Cursor Left
<
E7 Zoom
D#7 Cursor Right
>
C#7 Cursor Down
v
D5 Read
Automation
D#5 Write
Automation
E5 Sends
Automation
F5 Project
Automation
F#5 Mixer
Automation
G5 Motors
E3 Name/Value
Display
F3 SMPTE/Beats
Display
F#3 F1
Function
G3 F2
Function
G#3 F3
Function
A3 F4
Function
A#3 F5
Function
B3 F6
Function
C4 F7
Function
C#4 F8
Function
E0 Mute 1
Channel Mute
| C6 Left
F0 Mute 2
Channel Mute
| C#6Right
F#0 Mute 3
Channel Mute
| D6 Loop
G0 Mute 4
Channel Mute
| D#6-
G#0 Mute 5
Channel Mute
| E6 Previous
(Layer 2)
A0 Mute 6
Channel Mute
| F6 Add
(Layer 2)
A#0 Mute 7
Channel Mute
| F#6 Next
(Layer 2)
G6 Rewind
<<
G#6 FastForward
>>
G#5 Instrument
A5 Master
A#5 Solo Defeat
B5 Write
B0 Mute 8
Channel Mute
| F7 Scrub
D4 Group 1
Layer 2 (Fader Groups)
| F#4 Group 5
Layer 2 (Fader Groups)
D#4 Group 2
Layer 2 (Fader Groups)
| G4 Group 6
Layer 2 (Fader Groups)
E4 Group 3
Layer 2 (Fader Groups)
| G#4Group 7
Layer 2 (Fader Groups)
F4 Group 4
Layer 2 (Fader Groups)
| A4 Group 8
Layer 2 (Fader Groups)
MIDI FunctionI nfo
MID
FunctionI nfo
Ch
1 Cubase Ch1Cubase
C1 Select 1
Channel Select
| G#1Encoder 1
Press Encoder
C#1 Select 2
Channel Select
| A1 Encoder 2
Press Encoder
D1 Select 3
Channel Select
| A#1 Encoder 3
Press Encoder
D#1 Select 4
Channel Select
| B1 Encoder 4
Press Encoder
E1 Select 5
Channel Select
| C2 Encoder 5
Press Encoder
F1 Select 6
Channel Select
| C#2Encoder 6
Press Encoder
F#1 Select 7
Channel Select
| D2 Encoder 7
Press Encoder
G1 Select 8
Channel Select
| D#2Encoder 8
Press Encoder
A6 Stop
A#6 Play
B6 Record
Main record
C7 Cursor Up
^
D7 Cursor Left
<
E7 Zoom
D#7 Cursor Right
>
C#7 Cursor Down
v
C-1 Rec 1
Channel Rec
| E2 Page Up
C#-1 Rec 2
Channel Rec
| F2 Page Down
D-1 Rec 3
Channel Rec
| F#2 Pan
Assignment
D#-1 Rec 4
Channel Rec
| G2 Plugin
Assignment
E-1 Rec 5
Channel Rec
| G#2EQ
Assignment
F-1 Rec 6
Channel Rec
| A2 FX Send
Assignment
F#-1 Rec 7
Channel Rec
| A#2 Bank Up
Bank 8 Channels
G-1 Rec 8
Channel Rec
| B2 Bank Down
Bank 8 Channels
D5 Read
Automation
D#5 Write
Automation
E5 Sends
Automation
F5 Project
Automation
F#5 Mixer
Automation
G5 Motors
E3 Name/Value
Display
F3 SMPTE/Beats
Display
G#-1 Solo 1
Channel Solo
| C3 Channel Up
Bank One Channel
A-1 Solo 2
Channel Solo
| C#3Channel Down
Bank One Channel
A#-1 Solo 3
Channel Solo
| D3 Flip
Fader Flip Mode
B-1 Solo 4
Channel Solo
| D#3-
C0 Solo 5
Channel Solo
| A#4 Undo
C#0 Solo 6
Channel Solo
| B4 Redo
D0 Solo 7
Channel Solo
| C5 Save
D#0 Solo 8
Channel Solo
| C#5-
F#3 F1
Function
G3 F2
Function
G#3 F3
Function
A3 F4
Function
A#3 F5
Function
B3 F6
Function
E0 Mute 1
Channel Mute
| C6 Left
F0 Mute 2
Channel Mute
| C#6Right
F#0 Mute 3
Channel Mute
| D6 Loop
G0 Mute 4
Channel Mute
| D#6-
G#0 Mute 5
Channel Mute
| E6 Previous
(Layer 2)
A0 Mute 6
Channel Mute
| F6 Add
(Layer 2)
A#0 Mute 7
Channel Mute
| F#6 Next
(Layer 2)
G6 Rewind
<<
G#6 FastForward
>>
G#5 Instrument
A5 Master
A#5 Solo Defeat
B0 Mute 8
Channel Mute
| F7 Scrub
<<<<<<<<< MCP MIDI Implementation >>>>>>>>>
This is a list of supported standard MCP functions in Logic Pro X and their MIDI CC control values.
Each CCtriggers the indicated function when the device is congured as an MCP device in the
DAW. Buttons can be assigned a custom CC value usingiMap software.
MIDI FunctionI nfoM IDMIDI FunctionI nfo
Ch
1 Logic Pro X Ch1 Logic Pro X
C1 Select 1
Channel Select
G#1 Encoder 1
Press Encoder
C#1 Select 2
Channel Select
A1 Encoder 2
Press Encoder
D1 Select 3
Channel Select
A#1 Encoder 3
Press Encoder
D#1 Select 4
Channel Select
B1 Encoder 4
Press Encoder
E1 Select 5
Channel Select
C2 Encoder 5
Press Encoder
F1 Select 6
Channel Select
C#2 Encoder 6
Press Encoder
F#1 Select 7
Channel Select
D2 Encoder 7
Press Encoder
G1 Select 8
Channel Select
D#2 Encoder 8
Press Encoder
C-1 Rec 1
Channel Rec
E2 Track
Assignment
C#-1 Rec 2
Channel Rec
F2 Send
Assignment
Logic Pro X

ICON PLATFORM NANO Specifications

General

Connectivity	USB
Compatibility	Windows, macOS
Power Supply	USB Bus Powered
Transport Controls	Yes
USB	USB 2.0
Footswitch	1 footswitch connector
Inputs	1 x Footswitch
Faders	1 x Touch-sensitive motorized fader with 10-bit resolution
Display	12-segment LED display
