ICON STAGE - 10. DMX PROTOCOL

ICON STAGE USER MANUAL
21
10. DMX PROTOCOL
DMX channel´s functions and their values (58 DMX channels):
Mode/Channel Value Function
St Ex
1 1
PAN Movement 8bit :
0-255 Pan Movement
2 2
Pan Fine 16bit
0-255 Fine control of Pan movement
3 3
TILT Movement 8bit :
0-255 Tilt Movement
4 4
Tilt Fine 16bit
0-255 Fine control of Tilt movement
5 5
Color Wheel and color change to
any position:
0-127 Cooler change to any position
15-17 Color 1 (center)
31-33 Color 2 (center)
47-49 Color 3 (center)
63-65 Color 4 (center)
79-81 Color 5 (center)
95-97 Color 6 (center)
111-113 Color 7 (center)
128-189 Forwards rainbow effect from fast to slow
190-193 No rotation
194-255 Backwards rainbow effect from slow to fast
6
Color Wheel Fine :
0-255 Color Wheel color change to any position Fine
6 7
Cyan Color :
0-255 Cyan (0-white, 255-100% Cyan)
8
Cyan Color Fine :
0-255 Cyan Fine
7 9
Magenta Color :
0-255 Magenta (0-white, 255-100% magenta)
10
Magenta Color Fine :
0-255 Magenta Fine
8 11
Yellow Color :
0-255 Yellow (0-white, 255-100% Yellow)
12
Yellow Color Fine :
0-255 Yellow Fine
9
13
CTO Color :
0-255 CTO (0-white, 255-100% CTO)
14
CTO Color Fine :
