0-255 CTO Fine
10 15
Rotating gobos, cont. rotation :
Gobo wheel index
(Gobo Scroll ON in the menu or Control channel)
0-5
Open
6~189 gobo change to any position
29 gobo 1 (center reference value)
52 gobo 2 (center reference value)
75 gobo 3 (center reference value)
98 gobo 4 (center reference value)
121 gobo 5 (center reference value)
144 gobo 6 (center reference value)
167 gobo 7 (center reference value)
(Gobo Scroll OFF in the menu or Control channel)
0-7 Open
8-17 Rot. gobo 1
18-27 Rot. gobo 2
28-37 Rot. gobo 3
38-47 Rot. gobo 4
48-57 Rot. gobo 5
58-67 Rot. gobo 6
68-77 Rot. gobo 7
78-93 Gobo 1 shake slow to fast
94-109 Gobo 2 shake slow to fast
110-125 Gobo 3 shake slow to fast
126-141 Gobo 4 shake slow to fast
142-157 Gobo 5 shake slow to fast
158-173 Gobo 6 shake slow to fast
174-189 Gobo 7 shake slow to fast
Gobo wheel rotation
190-221 Gobo wheel rotation forwards from fast to slow
222-223 Reserved
224-255 Gobo wheel rotation f backwards from slow to fast
11 16
Rotating gobo index, rotating gobo rotation :
0-127 Gobo indexing
128-189 Clock-wise rotation from fast to slow
190-193 No rotation
194-255 Counter clock-wise rotation from slow to fast
17
Rotating gobo indexing Fine
0-255 Fine indexing
12 18
Fixed Gobos :
(Gobo Scroll ON in the menu or Control channel)
0-9 Open
