ICON STAGE USER MANUAL
23
10~189 gobo change to any position
30 gobo 1 (center reference value)
50 gobo 2 (center reference value)
70 gobo 3 (center reference value)
90 gobo 4 (center reference value)
110 gobo 5 (center reference value)
130 gobo 6 (center reference value)
150 gobo 7 (center reference value)
170 gobo 8 (center reference value)
(Gobo Scroll OFF in the menu or Control channel)
0-29 Open
30-39 Gobo 1
40-49 Gobo 2
50-59 Gobo 3
60-69 Gobo 4
70-79 Gobo 5
80-89 Gobo 6
90-99 Gobo 7
100-109 Gobo 8
110-119 Gobo 1 shake slow to fast
120-129 Gobo 2 shake slow to fast
130-139 Gobo 3 shake slow to fast
140-149 Gobo 4 shake slow to fast
150-159 Gobo 5 shake slow to fast
160-169 Gobo 6 shake slow to fast
170-179 Gobo 7 shake slow to fast
180-189 Gobo 8 shake slow to fast
Gobo wheel rotation
190-221 Gobo wheel rotation forwards from fast to slow
222-223 No rotation
224-255 Gobo wheel rotation f backwards from slow to fast
13 19
Wheel Animation :
0-7 Close
8-127 Animation indexing
128-187 Clock-wise scroll from fast to slow
188-195 No rotation
196-255 Counter clock-wise scroll from slow to fast
14 20
Iris:
0-255 Max. diameter to Min. diameter
21
Iris Fine:
0-255 Iris Fine
15
22
Prism:
0-63 Open position (hole)
64-127 Prism
