Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 55 -
The following is an overview of the parameters contained in the IP Address Selection section:
Static IP: If no DHCP server is installed on the network, the network settings can be
configured manually. Refer to Section “Manual Configuration” for more details.
DHCP: The Dynamic Host Configuration Protocol (DHCP) is a network application
protocol that automatically assigns an IPv4 address to each device. Refer to Section
“Dynamic Configuration” for more details.
Note: The DHCP function doesn’t effective on IPv6.
Each tGW-700/GW-2200 connected to the network must have its own unique IP
address. This parameter is used to assign a specific IPv4 address.
This parameter is used to assign the subnet mask for the tGW-700/GW-2200. The
subnet mask indicates which portion of the IPv4 address is used to identify the local
network or subnet.
This parameter is used to assign the IPv4 Address of the Gateway to be used by the
tGW-700/GW-2200. A Gateway (or router) is a device that is used to connect an
individual network to one or more additional networks.
This parameter is used to set a user-defined MAC address, which must be in the format
FF-FF-FF-FF-FF-FF.
Each IPv6 device connected to the network must have a link-local address. It always
effective in the same link layer. It is auto-configured by EUI-64. If your environment
doesn’t support the IPv6, please ignore this field.
The tGW-700/GW-2200 supports stateless address auto configuration (SLAAC). It will
be configured by the Router automatically, and the default router is the link-local address
of the router. The router should provide the prefix and the tGW-700 will calculate the
Host ID by EUI-64. If your environment doesn’t support the SLAAC, please ignore this
field.
SLAAC Timeout
(SLAAC Watchdog)
This parameter is used to configure the SLAAC timeout value. If the SLAAC address
doesn’t be configured in the specified time, the system will be rebooted to configure the
SLAAC address again.
Timeout value range: 30 to 65535 (seconds); Disable = 0;
IPv6 User-defined Address
It can be defined by the User. It’s more convenient than using the link-local address in
the simple application. This address can be routed if the prefix as same as IPv6 SLAAC
Address. If your environment doesn’t support the IPv6, please ignore this field.
Click this button to save the revised settings to the tGW-700/GW-2200.
