Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 85 -
Step 1: Connecting to a network, a PC and a Power Supply
1. Confirm that the tGW-700/GW-2200 device is functioning correctly. For detailed information
regarding how to install, configure and operate your tGW-700/GW-2200 series module, refer to
Chapter 3 “Getting Started for tGW-700/GW-2200 series using IPv4”
,
Chapter 4 “Getting Started for
tGW-700/GW-2200 series using IPv6”
.
2. Connect both the tGW-700/GW-2200, the Slave Device (e.g. a tPET-P6 module, optional) and
your computer to the same sub network or the same Ethernet Switch. For detailed information
regarding RS-232/RS-422/485 wiring, refer to
Section 2.5 “Wiring Notes for RS-232/422/485
Interfaces”
.
The wiring diagram is as follows:
To Next Page
