Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 86 -
Step 2: Configuring the Ethernet Settings
Contact your Network Administrator to
obtain a correct and functioning network
configuration (including the IP Address, Mask
and Gateway details) for the
tGW-700/GW-2200 module. Also refer to
Chapter 3 “Getting Started for tGW-700/GW-2200
series using IPv4”
,
Chapter 4 “Getting Started for
tGW-700/GW-2200 series using IPv6”
for more
details.
Step 3: Configuring Pair-connection (TCP Client Mode) on the Web Server
for the tGW-700/GW-2200 module
1. Open the eSearch Utility to search for the tGW-700/GW-2200 modules connected to the
network. Click the name of the first tGW-700/GW-2200 module to select it, and then click the
“Web” button to launch a browser window to connect to the web server on the
tGW-700/GW-2200 module. Alternatively, you can enter the URL for tGW-700/GW-2200 in the
address bar of the browser.
2. When the login screen is displayed, enter the password (use the default password “admin”) in
the Password field, and then click the “Submit” button to display the configuration page.
