ICP 9MPT - Circulation Air Blower Data: *9 MPV050 Performance; *9 MPV050 Lo HEAT CFM vs. ESP; *9 MPV075 COOLING CFM vs. ESP

Two- Stage Multi Position Furnace
Service
Manual
46
440 08 2002 02
AL WAYS CHECK CURRENT TECHENICAL SUPPORT MANUAL
THIS DATA IS SUBJECT TO CHANGE WITHOUT NOTICE
Circulation Air Blower Data - *9MPV(A1 & A2)
Heating, Cooling & Continuous Airflow Settings
Figure 1
ESP²
²²
² W.C.
*9MPV050 COOLING
(CFM VS. EXTERNAL STATIC PRESSURE )
SCFM
0
200
400
600
800
1000
1200
1400
0.1 0.3 0.5 0.7 1
000
001
010
011
100
101
110
111
Figure 2
ESP²
²²
² W.C.
*9MPV050 Hi HEAT
(CFM VS. EXTERNAL STATIC PRESSURE )
SCFM
0
200
400
600
800
1000
1200
0.1 0.2 0.5 0.7 1
000
001
010
011
100
101,110,111
