SERVICE AND TECHNICAL SUPPORT MANUAL Gas Furnace: (F/G)9MVE
Specifications subject to change without notice.
440 04 4801 03 15
Table 5 COOLING
4
AND HEATING AIR DELIVERY - CFM (Bottom Return
5
with filter)
(SW1-5 and SW2−2 set to OFF, except as indicated. See notes 1 and 2)
Unit Size Cooling Switch Settings External Static Pressure (ESP)
SW2-8 SW2-7 SW2−6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
040-10
Clg Default: OFF OFF OFF 1125 1080 1020 970 905 855 805 755 700 635
Cooling (SW2)
OFF OFF ON 615 555 510 475 440 395 355 270 230 note 8
OFF ON OFF 785 740 695 665 630 590 565 520 485 450
OFF ON ON 990 950 910 875 850 815 770 720 670 615
ON OFF OFF 1125 1080 1020 970 905 855 805 755 700 635
ON OFF ON 1125 1080 1020 970 905 855 805 755 700 635
ON ON OFF 1125 1080 1020 970 905 855 805 755 700 635
ON ON ON 1125 1080 1020 970 905 855 805 755 700 635
Clg SW2: Maximum Clg Airflow
2
1125 1080 1020 970 905 855 805 755 700 635
Heating
(SW1)
High Heat Airflow
3
815 770 725 695 660 625 595 550 510 475
Low Heat Airflow
3
660 605 560 530 495 450 415 340 300 note 7
040-12
Clg Default: OFF OFF ON 575 540 490 435 385 See note 4
Cooling (SW2)
OFF ON OFF 770 725 685 640 600 560 515 480 See note 4
OFF ON ON 945 910 875 835 800 770 735 695 665 635
ON OFF OFF 1140 1105 1075 1040 1005 970 930 885 835 790
ON OFF ON 1250 1210 1165 1115 1065 1015 965 915 860 810
ON ON OFF 1250 1210 1165 1115 1065 1015 965 915 860 810
ON ON ON 1250 1210 1165 1115 1065 1015 965 915 860 810
Clg SW2: Maximum Clg Airflow
2
1250 1210 1165 1115 1065 1015 965 915 860 810
Heating
(SW1)
High Heat Airflow
3
860 825 785 745 705 670 630 595 565 525
Low Heat Airflow
3
650 595 545 500 460 415 365 320 275 note 7
060-12
Clg Default: OFF OFF OFF 1250 1210 1165 1115 1065 1015 955 895 815 745
OFF OFF ON 605 565 510 455 420 See note 4
OFF ON OFF 785 750 705 675 630 585 See note 4
OFF ON ON 955 920 895 860 825 785 755 720 685 650
ON OFF OFF 1135 1110 1080 1055 1020 990 935 880 825 745
ON OFF ON 1250 1210 1165 1115 1065 1015 955 895 815 745
ON ON OFF 1250 1210 1165 1115 1065 1015 955 895 815 745
ON ON ON 1250 1210 1165 1115 1065 1015 955 895 815 745
Clg SW2: Maximum Clg Airflow
2
1250 1210 1165 1115 1065 1015 955 895 815 745
Heating
(SW1)
High Heat Airflow
3
1125 1100 1070 1045 1010 980 925 875 820 740
Low Heat Airflow
3
900 865 835 800 760 720 690 650 610 580
060-14
Clg Default: OFF OFF OFF 1330 1295 1260 1220 1190 1150 1110 1075 1045 1005
Cooling (SW2)
OFF OFF ON 725 600 435 280 210 See note 4
OFF ON OFF 780 725 660 615 540 See note 4
OFF ON ON 975 925 875 835 785 750 690 655 610 570
ON OFF OFF 1160 1120 1090 1045 1010 970 920 885 840 800
ON OFF ON 1330 1295 1260 1220 1190 1150 1110 1075 1045 1005
ON ON OFF 1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
ON ON ON 1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
Clg SW2: Maximum Clg Airflow
2
1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
Heating
(SW1)
High Heat Airflow
3
1145 1105 1075 1030 995 955 905 870 825 785
Low Heat Airflow
3
870 820 760 720 655 620 560 525 470 435
080-16
Clg Default: OFF OFF OFF 1805 1765 1720 1665 1610 1540 1475 1400 1315 1235
Cooling (SW2)
OFF OFF ON 775 635 455 230 See note 8
OFF ON OFF 840 740 675 625 555 See note 4
OFF ON ON 995 955 910 860 815 770 720 660 620 585
ON OFF OFF 1175 1140 1090 1060 1025 980 940 905 855 815
ON OFF ON 1325 1280 1245 1210 1180 1140 1105 1070 1025 990
ON ON OFF 1545 1515 1480 1445 1410 1380 1350 1315 1245 1175
ON ON ON 1805 1765 1720 1665 1610 1540 1475 1400 1315 1235
Clg SW2: Maximum Clg Airflow
2
1805 1765 1720 1665 1610 1540 1475 1400 1315 1235
Heating
(SW1)
High Heat Airflow
3
1520 1490 1455 1420 1385 1355 1320 1285 1220 1155
Low Heat Airflow
3
1180 1145 1095 1065 1030 985 945 910 860 820
