633GC SHOP MANUAL
13.7 Remove wrist pin bearing.
13.8 Cylinder gasket
A Oil gasket with ICS
®
2-stroke
engine oil.
B Install gasket and align holes and
notch.
13.9 Install wrist pin bearing in rod.
A Oil bearing with ICS
®
2-stroke
engine oil.
13. CYLINDER & PISTON
