633GC SHOP MANUAL
22 This section covers the removal
and installation of the chain
tensioner.
22.1 Remove bar plate to expose the
chain tensioner.
22.2 Unscrew tensioner to remove.
A Remove tensioner pin.
B Remove tensioner screw keeper.
22.3 Assemble in reverse order.
22. TENSIONER
