633GC SHOP MANUAL
EXHAUST
INTAKE
13.13 Make sure wrist pin retaining clip is in
the proper orientation.
13.14 Lubricate wrist pin and partially install
in piston.
13.15 Align piston in correct orientation.
13. CYLINDER & PISTON
