Vandal-proof Silicone Seal
Before installing the vandal resistant cover, silicone is applied along the top and side edges of the card reader to
ensure a sealed vandal-proof installation and maintain the impact protection rating.
The silicone is applied after the reader has been mounted, forming an exact fit at the mounting location.
⦁ Ensure that the bottom of the reader is not sealed, so that the faceplate can still be removed.
⦁ Be careful not to leave excess silicone which may impede the VRC mounting.
⦁ To ensure an exact seal, the VRCshould ideally be mounted before the silicone sets.
The diagram below demonstrates the placement of the silicone seal.
TSL Multi-Technology Card Reader | Installation Manual 17
