Technical Specifications
The following specifications are important and vital to the correct operation of this product. Failure to adhere to
the specifications will result in any warranty or guarantee that was provided becoming null and void.
Ordering Information
Order Codes See Reader Editions.
Power Supply
Operating Voltage 12VDC (9.5 to 14VDC)
Operating Current 120mA (Peak, Reading)
Communications
Card Read Range
MIFARE: 50mm (1.97")
DESFire EV1 ISO: 5mm (0.2")
DESFire EV2 ISO: 25mm (0.98")
DESFire EV3 ISO: 20mm (0.79")
125kHz Clamshell: 45mm (1.78”) *
Tag Read Range
MIFARE: 25mm (0.98")
DESFire EV1: 5mm (0.2")
DESFire EV2: 5mm (0.2")
DESFire EV3: 10mm (0.39")
125kHz: 25mm (0.98”) *
Wiegand Interface Multiple format 26, 34 or 37, customizable; Bit data 0 and data 1 sent at 1kHz.
Frequency
13.56 MHz ISO/IEC 14443 Type A
125KHz carrier. Several modulation formats are supported. *
Multi Conductor Cable
Module comms / RS-485: Belden 9842 or equivalent.
Max distance 900m (3000ft)
Wiegand: 22Awg alpha 5196, 5198, 18Awg alpha 5386, 5388.
Max Distance 150m (492ft)
OSDPCommunication OSDP standard 2.2 with Secure Channel Protocol
Bluetooth® Wireless Technology
Bluetooth® Read Range
Proximity mode: up to 0.5m (1.6ft) configurable
Action unlock (shake): up to 5m (16.4ft) configurable
Bluetooth® Electronic Credential
Transmission Technology
Bluetooth® version 5.1 compliant
Proprietary data exchange protocol. AES-128 encrypted
Reader App Version: 1.04.175 and above
Credentials can be distinguished by unique site code and card number
Bluetooth® Wireless Device Protege Mobile 1.0.x
NFC
NFC Read Range Up to 60mm
TSL Multi-Technology Card Reader | Installation Manual 36
