NFC (Near-field communication)
electronic credential transmission
technology
Android 4.4 or above, with phones which support ISO7816-4
Proprietary Secured DESFire credential
Credential is AES-256 (NIST certified AES algorithm)
Credentials can be distinguished by unique site code and card number
NFC Wireless Device Protege Mobile 1.0.x
Operating Conditions
Environment IP Rating IP65
Operating Temperature UL/ULC -35° to 66°C (-31° to 151°F) : EU EN -40° to 70°C (-40° to 158°F)
Storage Temperature -10˚ to 85˚C (14˚ to 185˚F)
Mean Time Between Failures
(MTBF)
520,834 hours (calculated using RFD 2000 (UTE C 80-810) Standard)
Dimensions (H x W x D)
Standard Reader 117 x 43 x 9.5mm (4.61 x 1.69 x 0.37")
Extra Reader 117 x 75 x 11.5mm (4.61 x 2.95 x 0.45”)
Mini Reader 87 x 43 x 9.5mm (3.43 x 1.69 x 0.37”)
Vandal Resistant Cover Dimensions
Standard Reader VRC 162 x 89 x 11.7mm (6.38 x 3.50 x 0.46")
Extra Reader VRC 162 x 121 x 11.7mm (6.38 x 4.76 x 0.46")
Surface Mount Box Dimensions
Standard Reader SMB TBC
Extra Reader SMB TBC
Weights Net Weight Gross Weight
Standard Reader 60g (2.1oz) 100g (3.5oz)
Extra Reader 120g (4.2oz) 130g (4.6oz)
Mini Reader 40g (1.4oz) 90g (3.2oz)
Vandal Resistant Cover Weights Net Weight Gross Weight
Standard Reader VRC TBC TBC
Extra Reader VRC TBC TBC
Surface Mount Box Weights Net Weight Gross Weight
Standard Reader SMB 50g (1.8oz) 70g (2.5oz)
Extra Reader SMB 70g (2.5oz) 100g (3.5oz)
Faceplate Weights Net Weight Gross Weight
Standard Reader Faceplate 10g (0.4oz) 20g (0.7oz)
Extra Reader Faceplate 30g (1.1oz) 40g (1.4oz)
Mini Reader Faceplate 10g (0.4oz) 20g (0.7oz)
Pigtail Cable Weights Net Weight Gross Weight
Standard 34cm Pigtail Cable TBC TBC
TSL Multi-Technology Card Reader | Installation Manual 37
