ICT TSL-STD-RR-HL - TSL Extra Reader Vandal Resistant Cover

TSL Extra Reader Vandal Resistant Cover
The dimensions shown below outline the essential details needed to help ensure the correct installation of the ICT
TSL Extra Reader Vandal Resistant Cover. All measurements are shown in millimeters.
121.00mm 4.764in
162.00mm
6.378in
60.50mm 2.382in 60.50mm 2.382in
29.00mm
1.142in
41.50mm
1.634in
41.50mm
1.634in
29.00mm
1.142in
5.3mm 0.207in
Mounting Holes
11.70mm 0.461in
TSL Multi-Technology Card Reader | Installation Manual 35
