27
Classic LX, RS - Installation
Key No. G.C. Part No. Description Qty. Product No.
11 308 365 Sightglass assembly kit. 1 079 602
15 Main burner
379 917 AEROMATIC No. AC 19/123 294; RS 230. 1 111707
379 918 AEROMATIC No. AC 19/123 293; RS 240 & RS 250. 1 111708
379 919 AEROMATIC No. AC 19/123 292; RS 260. 1 111709
16 Main burner injector
398 043 BRAY Cat. 10 - size 800; RS 230. 1 111 988
398 048 BRAY Cat. 10 - size 1050; RS 240. 1 004 368
398 054 BRAY Cat. 10 - size 1350; RS 250. 1 004 980
398 587 BRAY Cat. 10 - size 1550; RS 260. 1 111 989
17 386 131 Pilot burner injector HONEYWELL 4580 10 7501. 1 004 981
18 308 358 Pilot burner HONEYWELL Q359 A 1124. 1 079 599
20 Gas valve kit ( V4600A1122 - 230 V) 1 075 697
22 395 705 Piezo unit, VERNITRON 60080. 1 003 939
23 308 549 Ignition electrode. Morgan Matroc 410 lg. 1 111 881
24 391 519 Thermocouple, HONEYWELL Q 309 A 3299, 600mm lg. 1 111 880
25 308 521 Control box, including thermostat, thermostat knob and
suppressor assembly. 1 111 974
26 386 139 Thermostat, RANCO K 36 - L 1016 with 48" capillary. 1 113 193
27 308 012 Thermostat knob1 013 909
30 308 523 Boiler casing assembly - white stove enamel, with
sightglass and foil insulation (Standard model only). 1 079 932
31 308 524 Controls casing door - white plastic, with Lighting
Instructions (Standard model only). 1 079 937
34 308 329 Boiler sealing pack. 1 079 594
39 308 507 Overheat thermostat, RANCO LM 7 - P 5054
(sealed systems only). 1 100 787
40 - Boiler casing assembly - white stove enamel with
sightglass and foil insulation (Deluxe model only). 1 112 731
41 - Glass fascia (Deluxe model only). 1 112 733
42 - Plastic fascia trim (Deluxe model only) - beige. 2 138 251
43 - Plastic fascia trim (Deluxe model only) - white. 2 138 406
44 - Controls casing bottom panel. 1 138 267
SHORT LIST OF PARTS
When ordering please quote:
1. Boiler model
2. Appliance G.C. number
3. Description
4. Quantity
5. Product no.
The following list is comprised of parts commonly required as
replacement components, due to damage or expendability. Their
failure or absence is likely to affect safety or performance.
The list is extracted from the British Gas List of Parts, which
contains all available spare parts.
The full list is held by British Gas, Caradon Plumbing Limited
distributors and merchants.
