Fig. 49 - Right Side View EXALT Solo 110

103

CHAPTER 19

CHAPTER 19 - PRODUCT SPECIFICATIONS

L M N O P Q R

Items

/" NPSC Relief

Valve

3" Combustion

Air Inlet & 3" Vent

Outlet

1" NPT Boiler

Return

Condensate

Drain

1" NPT Boiler

Supply

/" Gas

Connection

Boiler Depth

Dimension

inches

[mm]

7 /

[195]

3 /

[100]

3 /

[90]

3 /

[100]

7 /

[195]

11 /

[295]

17 /

[435]
