icos - Installation & Servicing
DOCUMENT AMENDMENTS
Relevant Installation changes implemented in this book from Mod Level ........... A04 (Apr 08) to A05 (Sep 09)
Ideal Stelrad Group reserve the right to vary specification without notice
Page 7, Optional Extra Kits
• Addition of Concentric flue Screw Retaining Kit & Adjustable Flue Support Bracket
Page 8, Flue Installation - Table 3
• Item 14 - new dimensions
Page 16, Frame 12 - Determining the Flue Lengths and Packs Required
• New flue kit added.
• Notes - Items 4 & 5 added
Page 18, Frame 18 - Terminal Wall Seal Assembly / Position
• New frame added ref. positioning of terminal wall seal
Page 19, Frame 21 - Flue Extension Ducts
• Item no. 3 added.
Page 20, Frame 24 - Condensate Pipe Termination Configurations
• Update drawing 1 and note added ref BS6798
Page 29, Frame 37 - Pictorial Wiring Diagram
• Updated drawing showing removal of bracket from spark generator
Page 42, Frame 65 - Combustion Chamber Insulation Replacement
• Updated Frame to reflect new insulation.
Page 48, Frame 76 - H9/L9 Heat Exchanger Overheat
• New flow chart.
Page 49 - Short Parts List
• New updated parts list
Page 52 - Code of Practice
• New Code of Practice Guidelines added.
