icos - Installation & Servicing
SHORT LIST OF PARTS
The following are parts commonly required due to damage or
expendability. Their failure or absence is likely to affect safety or
performance of this appliance.
The list is extracted from the British Gas List of Parts, which
contains all available spare parts.
The full list is held by British Gas Services, Ideal Stelrad Group
distributors and merchants.
When ordering spares please quote:
1. Boiler Model
2. Appliance G.C. Number
3. Description
4. Quantity
5. Product Number
1 Front casing panel 1 173 508
4 E67-482 Bottom casing panel 1 170 900
11 E67-489 Burner 1 170 905
12 Combustion chamber insulation 1 173 520
14 E67-492 Injector and housing HE15, HE18, HE24 1 170 908
H18-545 Injector and housing HE12 1 173 779
16 E85-097 Fan assembly 1 172 625
19 E67-497 Gas control valve 1 170 913
22 E67-500 Flue thermistor 1 170 916
23 E67-501 Control thermistor 2 170 917
24 E67-502 Overheat thermostat 1 170 918
25 Ignition electrode kit 1 175 406
26 Flame detection electrode and gasket 1 173 529
32 E67-511 Condensate ‘S’ trap 1 170 926
34 E65-515 Controls hinge bracket kit 1 170 928
35 User controls 1 173 532
36 PCB primary controls kit (V9) 1 174 486
37 E67-519 Fuse PCB (3.15A L 250V) 1 170 931
39 Main switch c/w harness 1 173 537
45 E65-527 Gasket kit 1 170 938
52 E68-376 Seal kit - sealing panel 1 171 014
53 E68-380 Turret gasket 1 171 022
40 Spark generator 1 173 538
94 Ignition lead 1 175 424
95 Detection lead 1 173 511
Key No. GC Part No. Description Qty. Product No.
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance specification
that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers Limited.
