Installation and Servicing
Section 1 - General
Boiler Page
Make and model .........................................................7
Appliance serial no. on data badge .......... Front Cover
SEDBUK No. % ..........................................................6
Controls
Time and temperature control to heating ................. 27
Time and temperature control to hot water ............. 27
Heating zone valves ................................................ n/a
TRV’s........................................................................ 10
Auto bypass .............................................................10
Boiler interlock ..........................................................10
For all boilers
Flushing to BS.7593 .................................................13
Inhibitor .................................................................... 13
Central heating mode
Heat input ...................................................to be calculated
For assistance call
Technical Helpline
01482 498663
Page
Burner operating pressure ...................................... n/a
Central heating ow temp. ...........measure and record
Central heating return temp. ........measure and record
For combination boilers only
Scale reducer ........................................................... 13
Hot water mode
Heat input ............................................ to be calculated
Max. operating burner pressure .............................. n/a
Max. operating water pressure ........ measure & record
Cold water inlet temp ...................... measure & record
Hot water outlet temp. ..................... measure & record
Water ow rate at max. setting ........ measure & record
For condensing boilers only
Condensate drain ................................................ 23-24
For all boilers: Complete, sign & hand over to customer
For UK, to comply with Building Regulations Part L1 (Part 6 in Scotland) the boiler should be tted in accordance with the
manufacturer’s instructions. Self-certication that the boiler has been installed to comply with Building Regulations can be
demonstrated by completing and signing the Benchmark Commissioning Checklist.
Before installing this boiler, read the Code of Practice sheet at the rear of this book.
BENCHMARK COMMISSIONING CHECKLIST DETAILS
NOTE TO THE INSTALLER: COMPLETE THE BENCHMARK COMMISSIONING CHECKLIST
AND LEAVE THESE INSTRUCTIONS WITH APPLIANCE
Natural Gas Only
Destination Country: GB
LOGIC+ SYSTEM
2
S
BOILER SIZE
G.C. Applicance No
(Benchmark No.)
15
41-796-93
18
41-796-94
24 41-796-95
30
41-796-96
