Installation
HR9Z-B2192 8/2020 53
Safety-Related Inputs
The device provides two safety-related inputs. Each safety-related input consists of one control
output DC+ (terminals S11, S21) and one input channel CH+ (terminals S12, S22).
Each control output DC+ provides a nominal voltage of 24 VDC to the connected sensor/device. It
is also used for dynamization
(see page 43)
.
Respect the maximum wire resistance of 500 Ω when determining the cable length. The maximum
wire length between a safety-related input and a sensor/device is 30 m (98.43 ft) if the supply via
the control outputs (terminals S#1) of the safety-related inputs are not used.
Wire the terminals of the safety-related inputs according to the wiring diagram for the application
function
(see page 58)
to be implemented.
Safety-Related Outputs
The wiring of the safety-related outputs depends on the safety-related function to be implemented.
Install fuses with the rating specified in the chapter Electrical Characteristics
(see page 28)
.
13, 14, 23, 24, 33, 34 Terminals of the safety-related outputs
Z1 Pulsed output for diagnostics
(see page 79)
, not
safety-related
EXT Connector for output extension module HR6S-EP
Terminal Designation Explanation
WARNING
INSUFFICIENT AND/OR INEFFECTIVE SAFETY-RELATED FUNCTIONS
Only connect a sensor/device to a safety-related input that meets all requirements as per your
risk assessment and that complies with all regulations, standards, and process definitions
applicable to your machine/process.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
