Functions
HR9Z-B2192 8/2020 63
Application Function 5
Synchronization:
Wiring of the inputs for sensors/devices with PNP output
Characteristic Value/Description
Typical applications Monitoring of proximity switches
Type of outputs of sensor/device providing the input signal
for application function
One PNP output
S## terminals to be connected S12 and S22
Dynamization No
Signal interlock monitoring Between terminals S12 and S22
Synchronized terminals Synchronization time
S12 synchronized with S22 S12 and S22 have to be activated within 0.5 s.
