14
7. Turn the silver fasteners clockwise a quarter
turn to lock the base into place.
8. Ensure the base and silver fasteners
are flush with the analyzer and locked
into place. Not locking the base and
fasteners properly can impact analyzer
performance.
Cleaning the Case and Screen (To Be Performed As Needed)
Clean the case and screen using a lint-free cloth dampened with 70% isopropyl alcohol, mild liquid
soap and water, or a 10% bleach solution. DO NOT wipe the vents underneath the power button or
the USB/power/Ethernet ports.
Replacing the Batteries
The analyzer uses two different types of batteries:
• Two 3.7 V DC, 2,600 mAh batteries
• One 3 V DC, 48 mAh button cell battery
Note: IDEXX recommends replacing all batteries at the same time. Contact IDEXX Laboratories to
obtain replacement batteries.
This symbol is placed in accordance with the European Union Directive 2002/96 on the
Waste Electrical and Electronic Equipment (the WEEE Directive). If disposed of within
the European Union, this product should be treated and recycled in accordance with
the laws of your jurisdiction implementing the WEEE Directive. For additional information,
visit idexx.com/weee.
To Replace the Two 3.7 V DC, 2,600 mAh Batteries
1. Power off and unplug the analyzer.
2. Open the battery compartment on the back of the analyzer by
pressing down on the latch on the top of the door.
3. Remove the two batteries from the compartment.
4. Insert two new batteries, negative end first, into the
compartment.
5. Close the battery compartment.
Note: It will take up to 8 hours to fully charge the analyzer (the
status light will turn green when fully charged). The analyzer may
be used while charging.
Maintenance and Troubleshooting
