BIBD-ICP User’s Manual
SATA
2x
SATA II up to 3Gb/s HDD connector (SATA2 is shared with mini PCI-E slot)
Display
1x
2*20 pins, LCD LVDS connector support Dual Channel
1x
1*8 pins, LCD Backlight Inverter power connector
1x
1*3 pins, LCD Backlight power select jumper(3.3V/5V)
1x
1*3 pins, LCD Inverter power select jumper(5V/12V)
1x
1*3 pins, Backlight control mode select jumper
1x
1*3 pins, Backlight PWM signal select jumper
Speaker
2x
1*2 pins for Amplifier output ALC105 class D 3Watt/Channel Amplifier
1x buzzer
On Board Connectors
Power
1x 2*2 pins + 12V DC-in connector(Share with rear DC Jack)
& Headers
2x
1*4 pins for HDD power 5V
I/O
1x
2*5 pins, USB2.0 pin header support 2 USB devices
1x
2*5 pins, USB3.0 pin header support 1 USB device
4x
2*5 pins COM3/4/5/6, RS232, support Ring/5/12V 2*3 pins power select
1x
2*5 pins header, digital IO support 4 in 4 out
1x
2*13 pins, parallel header for printer
2x
1*3 pins, system fan and CPU smart fan header
1x
2*5 pins front panel as Power/Reset/HDD/LAN header
1x
1*6 pins box header, internal cash drawer
1 x 1*6 pins MSR pin header
2 x 1*3 pins jumper, MSR definition change
1 x 1*6 pins header, SIM card
Board Size
170 mm (W) x 170 mm (L), Mini-ITX
Operation Temperature
0°C ~ 60°C
Storage Temperature
-20°C ~ 80°C
Relative Humidity
10% ~ 90% (non-condensing)
Win 7, Win 8, POSReady, Linux Fedora 14, Intel® Embedded Graphics Drivers Version 10 (Support by Intel
OS Support
EIA IEGD tools)
Biostar reserves the right to add or remove support for any OS with or without notice.
