6
3.2 RFID antennas
The device supports up to four RFID read/write heads of type ANT41x / ANT51x
from ifm electronic gmbh�
You can find information about the matching read/write heads on our website at:
www�ifm�com
→ data sheet search → ANT41 or ANT51
4 Function
You can find detailed information about the function of the system in the device
manual at:
www�ifm�com
→ data sheet search → DTE101 → Operating instructions
5 Installation
5.1 Installation distance
Due to the internal heating of the device a minimum distance to other objects of
10 mm is to be taken into account during installation�
A = 10 mm
