diS Update rate and orientation of the display:
d1 = update of the measured values every 50 ms�
d2 = update of the measured values every 200 ms�
d3 = update of the measured values every 600 ms�
rd1, rd2, rd3 = display as for d1, d2, d3; rotated by 180°�
OFF = The measured value display is deactivated in the RUN
mode� The LEDs remain active even if the display is deac-
tivated� Error messages are displayed even if the display is
deactivated�
coLr Colour configuration of the display (→ 3.2):
rEd = Display always red�
GrEn = Display always green�
rxou = Display red in case of switched output OUTx�
Gxou = Display green in case of switched output OUTx�
r-12 = Display red if measured value is between the limit values of OUT1
and OUT2�
G-12 = Display green if measured value is between the limit values of OUT1
and OUT2�
r-cF = Display red if measured value between limit values cFL���cFH,
irrespective of the output function�
G-cF = Display green if measured value between limit values cFL���cFH,
irrespective of the output function�
8 Parameter setting
Parameters can be set before installation and set-up of the unit or during operation�
If you change parameters during operation, this will influence the function
of the plant�
► Ensure that there will be no malfunctions in your plant�
During parameter setting the unit remains in the operating mode� It continues to
monitor with the existing parameter until the parameter setting has been completed�
The parameters can also be set via the IO-Link interface (→ 3.3)�
