16
8.1.8 Read the min/max values
► Select [Hi] or [Lo] and read the value�
[Hi] = max� value, [Lo] = min� value�
Delete memory:
► Select [Hi�T] or [Lo�T]�
► Briefly press [●].
► Keep [▲] or [▼] pressed.
> [----] is displayed�
► Briefly press [●].
It makes sense to delete the memories as soon as the unit operates
under normal operating conditions for the first time�
[Hi]
[Lo]
9 Operation
After power on, the unit is in the RUN mode (= normal operating mode)� It carries
out its measurement and evaluation functions and provides output signals accord-
ing to the set parameters�
9.1 Reading of the set parameters
► Briefly press [●].
► Click [▼] to select the parameter.
► Briefly press [●].
> The unit displays the corresponding parameter value for about 30 s� After that
the unit returns to the RUN mode�
9.2 Error indications / self-diagnostics
Diplay Warning message
[SCx] Excessive current at OUTx� LEDx for OUTx flashing�
[SC] Excessive current at both outputs� LED1 and LED2 flashing�
[OL] Detection zone exceeded�
[UL] Below the detection zone�
[C�Loc] Setting pushbuttons locked, parameter change rejected�
Active IO-Link communication�
