12
• Change from menu level 1 to menu level 2:
► Press [Mode/Enter] until [EF] is
displayed�
If the submenu is protected with an ac-
cess code,"Cod1" flashes in the display�
► Press [Set] and keep it pressed until
the valid code no� is displayed�
► Press [Mode/Enter] briefly�
On delivery by ifm electronic: no access
restriction�
 
► Press [Set] briefly�
> The first parameter of the sub-menu
is displayed (here: [Uni])�
 
With the user interface of the ifm Container program:
► Activate the [EF] button�
If menu level 2 is protected by an access code, the input field for the code no� is
activated�
► Enter valid code no�
• Locking / unlocking
The unit can be locked electronically to prevent unintentional settings�
► Make sure that the unit is in the
normal operating mode�
► Press [Mode/Enter] + [Set] for 10 s�
> [Loc] is displayed�
 

During operation: [Loc] is briefly displayed if you try to change parameter values�
For unlocking:
► Press [Mode/Enter ] + [Set] for 10 s�
> [uLoc] is displayed�
 

On delivery: unlocked�
• Timeout:
If no button is pressed for 15 s during parameter setting, the unit returns to the operat-
ing mode with unchanged values�
