CompactModul Metall CR2032
12
Parameter Index in ob-
ject directory
Default
(factory preset)
Change automati-
cally saved
Change
effective
Event Timer Trans PDO1 1800 05 0x00 adjustable immediately
COB ID Trans PDO 2 1801 01 0x280 + Node ID adjustable after a reset
Trans Type Trans PDO 2 1801 02 0x01 (synchronous) adjustable immediately
Event Timer Trans PDO2 1801 05 0x00 adjustable immediately
The life time factor 0 is interpreted as 1�
The first guard protocol is assessed as "start guarding" even if guarding is not active at this time (guard time =
0)�
*) Observe the position of the hex-code switch!
Entries in the object directory are only valid if the hex-code switches for baud rate (S1) and/or node ID (S2,
S3) are in the position "F"�
(For position and coding of the hex-code switches see connecting and operating elements → 9 Technical data)
Explanation of the abbreviations:
0x��� = hexadecimal value
0b��� = bit coded
0d��� = decimal numerical value
str = string
rw = read-write
ro = read only
u8 = unsigned 8 bit
u16 = unsigned 16 bit
