6.2 Fuses
To protect the whole system (wiring and module) the individual electric circuits
must be protected�
Designation Potential Plug:Pin Fuse
Supply voltage module VBB
S
P/N1:01 2 A
Supply voltage outputs (group 1) VBB
O 01
X20:07 20 A
Supply voltage outputs (group 2) VBB
O 02
X21:07 20 A
