8.5.2 Override with command pulse
► Press override button
> Bridging the safety light curtains / light grids for max� 15 min�
The function can be started again by activating the override button at the following
conditions:
- max� 30 subsequent override command pulses
- max� total time of the override function = 60 min�
The override function ends automatically with clear protected area and free muting
sensors or when the 15 min have elapsed and the GUARD function will be activa-
ted without any further command�
The timer for the override command pulses and the total time of the override
function will be reset to 0�
9 Scale drawing
114,5
99
35
LEDs
