IFM G2001S - 5�1�3 LED States

8
5.1.3 LED states
Description
IN
FAIL
GUARD
BREAK
S1
S2
MUT.
LED
S1 S2 MUT.
yellow yellow yellow
Switch-on test
Object detected
No object detected
Muting active
Override request
/ /
Description
IN
FAIL
GUARD
BREAK
S1
S2
MUT.
LED
IN FAIL GUARD/BREAK
green red red yellow green
Switch-on test
Protected area interrupted,
relay outputs deactivated
Protected area clear,
relay output deactivated,
waiting for restart
Protected area clear,
relay outputs activated
