9.2 Parameter setting via the memory plug
Parameters can be set quickly and easily via a correctly set memory plug (memory
module, order no� E30398)�
► Load suitable parameter set (e�g� using a PC) to the memory plug
► Connect memory plug between sensor and socket
> When voltage is supplied, the parameter set can be transferred from the
memory plug to the sensor� Alternatively, a parameter can be written from the
sensor to the memory plug�
The memory plug can also be used to save the current parameter setting of
a unit and to transfer it to other units of the same type
You can find more information about the memory plug in the technical
documentation for the article E30398 (available free of charge at www�ifm�com)�
10 Operation
After power on, the unit is in the Run mode (= normal operating mode)� It carries
out its measurement and evaluation functions and generates output signals
according to the set parameters�
10.1 Operating and diagnostic messages via IO-Link
IODD and IODD descriptive text as a pdf file at:
www�ifm�com/gb/io-link�
10.2 Output response in different operating states
OUT1 *
)
OUT2
Initialisation Process value invalid OFF
Normal operation
Process value according to
the level
according to the level and
OU2 setting
Fault Process value invalid
4 mA / 0 V for FOU2 = OFF
20 mA / 10 V for FOU2 = on
*
)
process value via IO-Link
10.3 Setting ranges
[LEnG] mm inch
Setting range 100���1600 4�0���63
Step increment 5 0�2
