IFM LX Series User Manual

5
UK
3 Items supplied
• Level sensor LR9020 or LXxxxx
• Operating instructions
In addition, the following is necessary for installation and operation:
• Rod (for operation of the unit with single probe → 4.1)
• If required, 1 coaxial pipe (for operation of the unit with coaxial probe → 4.2)
• Mounting material (if necessary, a launching plate → 4.1).
Only use accessories from ifm electronic gmbh! The optimum function is
not ensured when using components from other manufacturers�
Available accessories: www�ifm�com
Set-up requires a PC with IO-Link compatible software or a memory plug
with corresponding programming� More information → 5.2.5 and → 9�
4 Functions and features
The unit continuously detects the level in tanks and generates output signals
according to the parameter settings�
2 outputs are available:
- OUT1: Level via IO-Link�
More information → 5.2.5 and → 9�
- OUT2: analogue signal proportional to the level 4���20 mA / 0���10 V
On delivery the device is not operational!
For set-up valid basic settings / parameters must be transferred to the
device (→ 9.1)� Ensure that the basic settings are entered correctly
according to the mounted probe and the medium to be detected�
