8.2 Modbus TCP data model
Input (PLC)
Source Type Size Use
Analogue inputs (DC)
<input name> Real 4 bytes Value of the signal connected
to the analogue input (IN1, IN2)
External inputs
<input name> Real 4 bytes Value of the external input (External_xx)
Objects
Time domain
<object name>
Value Real 4 bytes Object value in SI unit (m/s², m/s)
State Byte 1 byte (Alarm) state of the object
0: OK
1: warning alarm
2: damage alarm
3: inactive
4: error (description: see Error)
Error Word 2 bytes Error code for object state
Hex0000: no error
Hex0001: internal error
Hex0002: calculation error
Hex0004: speed out of range
Hex0008: speed unstable
Hex0010: invalid base line
Hex0020: invalid reference value (1)
Hex0040: invalid reference value (2)
Hex0100: deactivated by signal weighting
Hex0200: reference value out of range
Hex1000: warning alarm
Hex2000: damage alarm
Hex8000: object inactive (by variant)
Rotational
speed
Real 4 bytes Trigger - rotational speed
Reference
value
Real 4 bytes Trigger - reference value
Warning
alarm
Real 4 bytes Limits - warning alarm (relative)
Damage
alarm
Real 4 bytes Limits - damage alarm (relative)
Base line Real 4 bytes Limits - base line in SI unit
(m/s², m/s)
Frequency domain
<object name>
Value Real 4 bytes Object value in SI unit (m/s², m/s, m)
