6
The dynamic inputs can be used for
– vibration monitoring
– vibration diagnostics
– analysis of other dynamic signals
Alternatively, the dynamic inputs can also be used like an analogue input with an
analogue current signal (4���20 mA)�
The hardware outputs can be configured as 2 x binary (NO/NC) or as 1 x analogue
(0/4…20 mA) and 1 x binary (NO/NC)�
The outputs can be used for
– time-critical alarms (e�g� machine protection, response time up to 1 ms)
– alarm output
– analogue value output of values measured by the diagnostic electronics
The parameter setting interface (TCP/IP) is used for the communication between
the diagnostic electronics and a PC (e�g� VES004 parameter setting software)�
The parameter setting interface can be used for
– parameter setting of the device
– online data monitoring
– reading the history memory
– firmware update
The Modbus TCP ports are used for the communication between the diagnostic
electronics and a Modbus TCP client/master (e�g� PLC)�
The Modbus TCP interface can be used for
– transferring the current measured values, limits and alarm states of the
diagnostic electronics to the PLC
– reading the counter readings of the diagnostic electronics
– writing rotational speeds and other values from the PLC to the diagnostic
electronics
– writing teach values from the PLC to the diagnostic electronics
The device is not approved for safety-related tasks in the field of operator
protection�
5.1 Firmware
► Recommendation: Install the firmware to use all device functions�
The firmware can only be updated via the VES004 PC software� Only the firmware
of the entire device can be updated�
