8.7 Modbus TCP output function code

Function code Description

Code 3 (dec) read holding register

Code 6 (dec) write single holding register

Code 16 (dec) write multiple holding register

8.8 Modbus TCP exception response

The following exception codes are supported by VSE153

Function code Name

Code 01 Illegal function

Code 02 Illegal data address

Code 03 Illegal data value

Code 04 Server device failure

9 Factory setting

9.1 General factory setting

Request Parameter

Parameter set none

Host name no name assigned

IP address 192�168�0�1

TCP/IP port 3321

Subnet mask 255�255�255�0

Default gateway 192�168�0�244

MAC address defined in the production process

9.2 Factory setting VSE153 - Modbus TCP

There is read and write access to the device settings� The following default values

are set by the factory:

Request Parameter

IP address 192�168�0�100

Subnet mask 255�255�255�0

Gateway 192�168�0�244

Port 502
