15
Set time DINT 4 bytes
Set time, always UTC, format:
- VSE150: U32: 0x00ssmmhh
- VSE151: U32: 0x00hhmmss
- VSE152: U32: 0x00hhmmss
- VSE153: U32: 0x00hhmmss
Set counter ID Byte 1 byte Set ID (1���32) of the counter
Set counter value DINT 4 bytes Set value of the counter selected with the
ID (in seconds)
8.3 Register
8.3.1 Modbus TCP device identication register
Address Access Length
(word)
Request Parameter
39000 R 30 vendor name "ifm electronic"
39030 R 20 product name "VSE153"
39050 R 2 production status of
the unit
"AA"
39052 R 10 firmware version "V1�0�0"
39062 R 2 serial Number defined in the product process
39064 R 20 short description
device
diagnostic electronics VSE153
8.4 Modbus TCP register mapping input (FC4)
Register no. IEC61131 address Access Memory area
30001…30512 %IW0…%IW511 r input area
8.5 Modbus TCP input function code
function code Parameter
Code 4 (dec) read input register
8.6 Modbus TCP register mapping output (FC3, FC6 and FC16)
Register no. IEC61131 address Access Memory area
40001…40512 %QW0…%QW511 r/w output area
