14
Rotational
speed
Real 4 bytes Trigger - rotational speed
Reference
value
Real 4 bytes Trigger - reference value
Warning
alarm
Real 4 bytes Limits - warning alarm (relative)
Damage
alarm
Real 4 bytes Limits - damage alarm (relative)
Counter
<counter name> DINT 4 bytes Counter value (in seconds)
Alarms
<alarm name> Byte 1 byte Alarm state (0, 1)
General
Variant Byte 1 byte Current variant (0���31)
System mode Byte 1 byte System mode:
0 : self-test
1: supervise (normal monitoring)
2: set-up (parameter setting)
3: measure (spectrum, raw data)
4: start-up (system booting)
Self-test result Byte 1 byte Binary bit pattern
0: sensors OK
1: sensor 1 self-test failed
2: sensor 2 self-test failed
4: sensor 3 self-test failed
8: sensor 4 self-test failed
Current queue level Byte 1 byte Current level of the fieldbus
communication
Queue overflow counter DINT 4 bytes Overflow counter of the fieldbus
communication
Checksum error counter DINT 4 bytes Checksum error counter of the fieldbus
communication
Output (PLC)
External inputs
<input name> Real 4 bytes Set value of the external input (Exter
-
nal_xx)
Objects
<object name>
Base line Real 4 bytes Limits - set base line in SI unit (m/s², m/s,
m) to adapt the limits
General
Variant Byte 1 byte Set current variant (0���31)
Do self-test Byte 1 byte Do self-test (≠ 0)
